FRONT PLASTICS - F04-1

FRONT PLASTICS - F04-1

No.

01
P/N (SKU): 5ASV-041021-6001
Part Name: HEADLIGHT PANEL
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: null
Price: 100,00 € : 100,00 €
-+
02
P/N (SKU): 9060-040310
Part Name: CLAMP ASSY
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Price: 2,00 € : 2,00 €
-+
03
P/N (SKU): 5020-040049
Part Name: CLAMP ST4.8
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: ST4.8
Price: 1,50 € : 1,50 €
-+
04
P/N (SKU): 8030-040800-00001
Part Name: NUT CLIP M6
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: M6
Price: 1,50 € : 1,50 €
-+
05
P/N (SKU): 5ASV-041024-6000
Part Name: PIN SHAFT
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Price: 1,50 € : 1,50 €
-+
06
P/N (SKU): 30903-0252010
Part Name: SPLIT PINS
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: 2.5x20
Price: 1,50 € : 1,50 €
-+
07
P/N (SKU): 30006-060016810
Part Name: HEXAGON FLANGE BOLTS
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: M6×16
Price: 1,50 € : 1,50 €
-+
08
P/N (SKU): 30110-420130010
Part Name: SELF-TAPPING SCREW_ST4.2x13
Effective: 2021-07-05
Remarks: null
Alternative parts: 30110-421130010
Specification: PERFORMANCE GRADE 4.8_SURFACE TREATMENT: COLOR ZINC PLATED
Price: 1,50 € : 1,50 €
-+
09
P/N (SKU): 5ASV-041043-6000
Part Name: FRONT RH DECO PLATE
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Price: 9,00 € : 9,00 €
-+
10
P/N (SKU): 5ASV-041042-6000
Part Name: FRONT LH DECO PLATE
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Price: 12,00 € : 12,00 €
-+
11
P/N (SKU): 30110-480160010
Part Name: CROSS-RECESSED FLAT ROUND HEAD TAPPING SCREWS
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: ST4.
Price: 1,50 € : 1,50 €
-+
12
P/N (SKU): 5ASV-041023-6000
Part Name: FRONT RH HEADLIGHT GUARD
Effective: 2021-07-05
Remarks: null
Alternative parts: 5ASV-041023-5000
Price: 16,00 € : 16,00 €
13
P/N (SKU): 5ASV-041022-6000
Part Name: FRONT LH HEADLIGHT GUARD
Effective: 2021-07-05
Remarks: null
Alternative parts: 5ASV-041022-5000
Price: 16,00 € : 16,00 €
14
P/N (SKU): 5ASV-041031-6000
Part Name: FRONT INNER LOCK PANEL
Effective: 2021-07-05
Remarks: null
Alternative parts: 5ASV-041031-6R00
Price: 15,00 € : 15,00 €
15
P/N (SKU): 30006-060012810
Part Name: HEXAGON FLANGE BOLTS
Effective: 2021-07-05
Remarks: null
Alternative parts: 30006-060012870
Specification: M6×12
Price: 1,50 € : 1,50 €
16
P/N (SKU): 5ASV-190001-6000
Part Name: CFMOTO LOGO
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Price: 16,00 € : 16,00 €
-+
17
P/N (SKU): 5ASV-041041-6000-0EC00
Part Name: FRONT TOP COVER
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: ROYAL BLUE
Price: 268,00 € : 268,00 €
17
P/N (SKU): 5ASV-041041-6000-0RE00
Part Name: FRONT TOP COVER
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: TRUE TIMBER CAMO
Price: 455,00 € : 455,00 €
17
P/N (SKU): 5ASV-041041-6000-0HC00
Part Name: FRONT TOP COVER
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: VELOCITY GREY
Price: 268,00 € : 268,00 €
18
P/N (SKU): 7030-222253
Part Name: CARGO BOX DAMPER
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Price: 1,50 € : 1,50 €
19
P/N (SKU): 5ASV-041054-6000
Part Name: FRONT RH SIDE PANEL
Effective: 2021-07-05
Remarks: null
Alternative parts: 5ASV-041054-6001
Price: 21,00 € : 21,00 €
20
P/N (SKU): 6GU#-000201-6000
Part Name: INNER HEX SCREW M6x25
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Price: 1,50 € : 1,50 €
-+
21
P/N (SKU): 5ASV-040010-6000
Part Name: CABLE, FRONT PANEL
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Price: 2,50 € : 2,50 €
22
P/N (SKU): 30301-060412
Part Name: PLAIN WASHERS
Effective: 2021-07-05
Remarks: null
Alternative parts: null
Specification: φ6
Price: 1,50 € : 1,50 €
23
P/N (SKU): 5ASV-041053-6000
Part Name: FRONT LH SIED PANEL
Effective: 2021-07-05
Remarks: null
Alternative parts: 5ASV-041053-6001
Price: 21,00 € : 21,00 €
