FUEL TANK - F17

FUEL TANK - F17

No.

01
P/N (SKU): 9010-120200
Part Name: CAP, FUEL TANK
Effective: 2021-02-26
Alternative parts: 7030-120060
Price: 8,50 € : 8,50 €
02
P/N (SKU): 9010-120310
Part Name: RUBBER LINER, FUEL TANK
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
03
P/N (SKU): 9010-120007
Part Name: REAR CUSHION SLEEVE, FUEL TANK
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
04
P/N (SKU): 30006-060025840
Part Name: null
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
05
P/N (SKU): 6080-150921
Part Name: TOP COVER SEALING GASKET
Effective: 2021-02-26
Alternative parts: 6070-150921
Price: 4,00 € : 4,00 €
06
P/N (SKU): 30006-050012840
Part Name: BOLT
Effective: 2021-02-26
Alternative parts: 30006-050012810
Price: 1,50 € : 1,50 €
06
P/N (SKU): 30006-050010840
Part Name: null
Effective: 2021-02-26
Price: 2,00 € : 2,00 €
-+
07
P/N (SKU): 901F-150900
Part Name: FUEL PUMP
Effective: 2021-02-26
Alternative parts: 901F-150900-10000
Price: 199,00 € : 199,00 €
08
P/N (SKU): 6070-120400
Part Name: CLAMP(Φ14.5)
Effective: 2021-02-26
Specification: Dia14.5
Price: 1,50 € : 1,50 €
-+
09
P/N (SKU): 901F-120001
Part Name: EFI HIGH-PRESSURE FUEL HOSE
Effective: 2021-02-26
Remarks: is replaced by 901F-120001-00001
Alternative parts: 901F-120001-00001
Price: 30,00 € : 30,00 €
09
P/N (SKU): 901F-120001-00001
Part Name: EFI HIGH-PRESSURE FUEL HOSE
Effective: 2021-02-26
Price: 30,00 € : 30,00 €
-+
10
P/N (SKU): 30006-060016840
Part Name: BOLT M6x16
Effective: 2021-02-26
Alternative parts: 30006-060016810
Specification: MILITARY GREEN
Price: 1,50 € : 1,50 €
11
P/N (SKU): 901F-120002
Part Name: EFI FUEL PIPE SLEEVE
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
12
P/N (SKU): 901F-120100
Part Name: EFI FUEL TANK ASSY
Effective: 2021-02-26
Remarks: EURO
Price: 81,00 € : 81,00 €
-+
13
P/N (SKU): 9010-120008
Part Name: SPONGE PAD, FUEL TANK
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
14
P/N (SKU): 9010-120005
Part Name: CUSHION MAT, FUEL TANK
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
15
P/N (SKU): 9010-040042
Part Name: BOTTOM PLATE, FUEL TANK
Effective: 2021-02-26
Price: 29,00 € : 29,00 €
-+
16
P/N (SKU): 9010-120006
Part Name: FRONT RUBBER SLEEVE, FUEL TANK
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
17
P/N (SKU): 9010-170121
Part Name: SEAL RING
Effective: 2021-02-26
Price: 2,00 € : 2,00 €
-+
18
P/N (SKU): 9010-170120
Part Name: FUEL LEVEL SENSOR ASSY
Effective: 2021-02-26
Price: 16,00 € : 16,00 €
-+
19
P/N (SKU): 30006-060010840
Part Name: BOLT M6x10
Effective: 2021-02-26
Specification: MILITARY GREEN
Price: 1,50 € : 1,50 €
-+
20
P/N (SKU): 6090-120220
Part Name: EFI FUEL FILTER ASSY
Effective: 2021-02-26
Price: 16,00 € : 16,00 €
-+
20
P/N (SKU): 805A-120004
Part Name: EFI FUEL FILTER
Effective: 2021-02-26
Price: 11,00 € : 11,00 €
-+
21
P/N (SKU): 8010-120001
Part Name: RUBBER COLLAR, FUEL FILTER
Effective: 2021-02-26
Price: 1,50 € : 1,50 €
-+
22
P/N (SKU): 9010-120601
Part Name: HEAT INSULATION MAT, FUEL TANK
Effective: 2021-02-26
Alternative parts: 9010-120601-10000
Price: 17,00 € : 17,00 €
