COOLING SYSTEM - F23

COOLING SYSTEM - F23

No.

01
P/N (SKU): 30006-060012840
Part Name: BOLT M6x12
Effective: 2021-02-26
Alternative parts: 30006-060012810
Specification: M6x12
Price: 1,00 € : 1,00 €
02
P/N (SKU): 30301-060442
Part Name: WASHER
Effective: 2021-02-26
Remarks: φ10
Alternative parts: 30301-060412
Specification: 6
Price: 1,00 € : 1,00 €
03
P/N (SKU): 9010-180004
Part Name: RUBBER SLEEVE, RADIATOR
Effective: 2021-02-26
Alternative parts:
Price: 5,90 € : 5,90 €
-+
04
P/N (SKU): 9010-180010
Part Name: STEEL SLEEVE, RADIATIOR
Effective: 2021-02-26
Alternative parts:
Price: 1,00 € : 1,00 €
-+
05
P/N (SKU): 401B-180100
Part Name: RADIATOR ASSY
Effective: 2021-02-26
Remarks: Can be interchangeable if ordered with 401B-180003
Alternative parts:
Price: 166,90 € : 166,90 €
-+
05
P/N (SKU): 9010-180100-1000
Part Name: RADIATOR ASSY
Effective: 2021-02-26
Alternative parts:
Specification: STAINLESS STEEL
Price: 167,80 € : 167,80 €
-+
06
P/N (SKU): 9010-180300
Part Name: WATER FILLING PORT CAP
Effective: 2021-02-26
Alternative parts: 8010-180024
Price: 7,20 € : 7,20 €
07
P/N (SKU): 30112-060012440
Part Name:
Effective: 2021-02-26
Alternative parts:
Price: 1,80 € : 1,80 €
-+
08
P/N (SKU): 9010-180200-3000
Part Name: FAN@^MOTOR
Effective: 2021-02-26
Alternative parts:
Price: 106,80 € : 106,80 €
-+
08
P/N (SKU): 9010-180200-A000
Part Name: FAN@^MOTOR
Effective: 2021-02-26
Remarks: HUALIN；isreplaced by 9010-180200-3000+9010-180201
Alternative parts: 9010-180200-3000+9010-180201
Price: 61,20 € : 61,20 €
09
P/N (SKU): 0010-135000
Part Name: THERMO SWITCH
Effective: 2021-02-26
Remarks: 80±4℃,Non-waterproofed
Alternative parts:
Price: 14,80 € : 14,80 €
-+
10
P/N (SKU): 30601-112020
Part Name: CLAMP A12
Effective: 2021-02-26
Alternative parts: 30601-112010
Price: 1,00 € : 1,00 €
11
P/N (SKU): 8060-180001
Part Name: RESERVOIR WATER PIPE
Effective: 2021-02-26
Alternative parts:
Price: 6,90 € : 6,90 €
-+
12
P/N (SKU): 30601-108520
Part Name: CLAMP A8.5
Effective: 2021-02-26
Remarks: is replaced by 30601-108510
Alternative parts: 30601-109010
Price: 2,40 € : 2,40 €
13
P/N (SKU): 9010-180400-1000
Part Name: RESERVOIR TANK ASSY
Effective: 2021-02-26
Alternative parts:
Price: 15,30 € : 15,30 €
-+
14
P/N (SKU): 9010-180005
Part Name: RESERVOIR OVERFLOW HOSE
Effective: 2021-02-26
Alternative parts:
Price: 7,80 € : 7,80 €
-+
15
P/N (SKU): 0180-023500-0030
Part Name: CLAMP, WATER HOSE
Effective: 2021-02-26
Alternative parts: 9010-180007
Price: 2,70 € : 2,70 €
15
P/N (SKU): A000-180006
Part Name: CLAMP B30
Effective: 2021-02-26
Alternative parts:
Specification: B30
Price: 2,90 € : 2,90 €
-+
15
P/N (SKU): 9010-180007
Part Name: CLAMP, WATER HOSE
Effective: 2021-02-26
Alternative parts:
Price: 2,90 € : 2,90 €
-+
16
P/N (SKU): 9010-180002
Part Name: RADIATOR WATER OUTLET HOSE
Effective: 2021-02-26
Alternative parts:
Price: 20,80 € : 20,80 €
-+
17
P/N (SKU): 401B-180003
Part Name: RADIATOR WATER INLET HOSE
Effective: 2021-02-26
Alternative parts:
Price: 24,20 € : 24,20 €
-+
17
P/N (SKU): 9010-180003
Part Name: RADIATOR WATER INLET HOSE
Effective: 2021-02-26
Alternative parts:
Price: 20,80 € : 20,80 €
-+
18
P/N (SKU): 5190-001003
Part Name: MAIN BRACKET RUBBER DAMPER
Effective: 2021-02-26
Alternative parts:
Price: 1,00 € : 1,00 €
-+
19
P/N (SKU): 30006-060025840
Part Name:
Effective: 2021-02-26
Alternative parts:
Price: 1,00 € : 1,00 €
-+
20
P/N (SKU): 8010-180023
Part Name: RESERVOIR CAP
Effective: 2021-02-26
Alternative parts:
Price: 2,60 € : 2,60 €
-+
21
P/N (SKU): 8030-180302
Part Name: JOINT
Effective: 2021-02-26
Alternative parts:
Price: 1,80 € : 1,80 €
-+
22
P/N (SKU): 8010-180028
Part Name: RESERVOIR CONNECTING HOSE
Effective: 2021-02-26
Alternative parts:
Price: 1,60 € : 1,60 €
-+
